- Processor Main Frequency: Depends on CPU
- Use: Commercial
- Memory Capacity: ≥ 4GB
- Hard Drive Capacity: 1TB
- Model Number: X5A-L
- Processor Brand: Intel
- Processor Model: Alder Lake-N
- Type: Mini Desktop
- Graphics Card Type: Integrated Card
- Brand Name: Topton
- Origin: Mainland China
- Certification: CE,FCC,RoHS
- Type: MINI PC
- Feature: Fanless System 0.00dB
- Graphics: Intel UHD Graphics
- Case Material: Brushed Aluminum Alloy
- Color: Black/Grey by random
- Netwok Ethernet: 5*Intel i226-V 2.5G LANs
Notice
Some Linux systems like pfSense etc maybe have not released new kernel to match 12th Gen Alder Lake-N yet, suggest to install version of following systems: OPNsense 23.x, Proxmox 7.1.2(no need check graphic, then upgrade to 7.4 version) etc. Please make clear before buying, DO NOT open dispute because of system issue.
|
Processors |
Cores & Threads |
Cache |
Max Turbo Frequency |
TDP |
Graphics |
|
Intel N95 |
4 cores, 4 threads |
6M |
3.40 GHz |
15W |
Intel UHD Graphics 1200MHz 16EUS |
|
Intel N100 |
4 cores, 4 threads |
6M |
3.40 GHz |
6W |
Intel UHD Graphics 750MHz 24EUS |
|
Intel N200 |
4 cores, 4 threads |
6M |
3.70 GHz |
6W |
Intel UHD Graphics 750MHz 32EUS |
|
Intel Core i3-N305 |
8 cores, 8 threads |
6M |
3.80 GHz |
15W |
Intel UHD Graphics 1250MHz 32EUS |
Product Highlight
-5xIntel i226-V 2.5G RJ45 LANs, 4xUSB2.0.
-1xDDR5 SODIMM ram slot, support 4800MHz.
-Support triple storage: 2xM.2 2280 NVMe/PCIe3.0x1 2280 SSD+1×2.5 inch SATA3.0 SSD/HDD.
-1xTF card slot support storage and system boot.
-Support 4x4K display: 2xHDMI2.1, 1xDP1.4, 1xType-C(support 3-screens display at same time).
-Support wide voltage 12-19V input.
-Support TPM2.0, AES-NI, ESXI, PVE, Watchdog, Auto power on, RTC, PXE boot, Wake-on-LAN etc.
-Full Aluminum Alloy high quality solid-built shell with three-sided long tooth-fins, wide heat dissipation area for excellent cooling performance, exquisite production craft on outside design.
-Fanless system without cooling fan, noiselessness and durability fit for industrial grade field, work as long as 7×24 hours.
-Low consumption TDP and can be mounted back of monitor by VESA bracket(optional).
Package List
1xMini PC
1xPower Adapter
1xPower Cord
1xSATA power&data cable
1xScrews Bag
Internal 8010 cooling FAN cost US $9. If you need, pay at this link.
DO NOT buy Barebone Mini PC ("No Ram No Storage" bundle)If you are NOT IT technician. PC demands professional skill to assemble and debug. Barebone bundle had best to use Samsung, Skyhynix etc ORIGINAL brand ram and storage.
Welcome to click the picture of VESA Bracket to order together if you need:
500GB 2.5'' HDD add extra 50$, 1TB 2.5'' HDD add extra 65$, 2TB 2.5'' HDD add extra 100$.
Upgrading link:https://www.aliexpress.com/item/32738298207.html
(How many dollars to upgrade, pay how many pieces, US$1=1pcs, For example upgrade 1TB 2.5'' HDD, pay 65pcs for US$65, remember to leave message noting which one you upgrade for…)
